Zyxel NR2301 5G NR Portable Router Sort

Zyxel NR2301 5G NR Portable Router Sort

5G NR Portable Router

The Zyxel Networks NR2301 is a cutting-edge 5G NR Portable Router that complies with the 3GPP Release 16 standard, ensuring seamless compatibility with 4G networks.

Offering high-speed broadband service through WiFi 6, it provides enhanced network security and supports up to 32 connected devices. With its compact design, your subscribers can stay connected on the go, enjoying unparalleled connectivity and convenience.

Lightning-fast 5G connectivity everywhere you go

The NR2301 has 5G NR DL speeds of up to 3.4 Gbps and 4G LTE DL speeds of up to 1.6 Gbps*, increasing internet speed and reducing network latency.

Wide spectrum bandwidth accelerates internet speeds and reduces network latency for premium and time-sensitive connectivity services.

WiFi 6 technology for superior performance and coverage

The NR2301 supports the WiFi 6 (11ax) standard, offering speeds of up to 1.8 Gbps with 2x2 UL/DL MU-MIMO. The uplink MU-MIMO, Orthogonal Frequency Division Multiple Access (OFDMA) and beamforming technologies empower the NR2301 to deliver premium speed for multi-streaming data access and optimal WiFi experience without dead zones.

Specifikationer:

IP Networking

Supports IPv4/IPv6 dual stack (NDP IPv6)

DHCP Client/server

Supports ICMP

Virtual Private Network (VPN) passthrough

Supports NAT/NAPT

Supports DMZ

Supports DDNS

Routing

Supports Dynamic DNS for first APN

IP Firewall

Firewall can be enabled or disabled via GUI

Supports SPI firewall

Application-level firewall

Filters LAN MAC address

Filters LAN IP address

Supports port forwarding/triggering

Management

Supports local device management and firmware upgrade via Web GUI

PIN/PUK management

APN management

Operating frequency band selection

Supports UPnP IGD

FOTA remote firmware upgrade

Network selection

Data usage

WLAN feature

Filters LAN IP address

Wireless Protected Setup (WPS)

WiFi Multimedia (WMM)

Open, WPA2-PSK, WPA-PSK/WPA2-PSK, WPA3-SAE, WPA2-PSK/WPA3-SAE with AES security type

Multiple SSIDs/hide SSIDs

Supports MU-MIMO

WiFi-enabled devices: 32

Hardware specifications

5G NR interface

3GPP Release 16 standard-compliant

Supports DL 4×4 MIMO: n1/n3/n7/n38/n40/n41/n77/n78

Supports DL modulation QPSK, 16-QAM, 64-QAM and 256-QAM

Supports UL modulation QPSK, 16-QAM, 64-QAM and 256-QAM

Output power: Class 3 (23 dBm ± 2 dB)

Supports both NSA and SA modes

FDD: n1/n3/n5/n7/n8/n20/n28/n71/n75/n76/n77/n78

TDD: n38/n40/n41

Data rates:

5G NSA: DL 3.4 Gbps; UL 550 Mbps*

5G SA: DL 2.4 Gbps; UL 900 Mbps*

4G LTE interface

3GPP UE Category 19 standard-compliant

Supports DL 4×4 MIMO: B1/B3/B7/B38/B40/B41/B42/B43

Supports DL modulation QPSK, 16-QAM, 64-QAM and 256-QAM

Supports UL modulation QPSK, 16-QAM, 64-QAM and 256-QAM

Output power: Class 3 (23 dBm ± 2 dB)

Supports frequencies:

LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32

LTE-TDD: B38/B40/B41/B42/B43/B71

Peak data rates:

Max. DL 1.6 Gbps/UL 200 Mbps*

Wireless LAN Standards

802.11 a/b/g/n/ac/ax 2.4 GHz, data rate up to 574 Mbps*

802.11 a/n/ac/ax 5 GHz, data rate up to 1200 Mbps*

Hardware interface

One power on/off button

2.4” LED display

One type-c USB 3.1 quick charging

One reset button

One Nano-SIM card slot

One menu-confirm button

One menu-select button

Two TS9 external antenna connectors

Power consumption

15 W (5 V/3 A @QC)/18 W (9 V/2 A @PD 2.0) quick charging

Physical specifications

Item

Dimensions (WxDxH): 137.5 x 72 x 16.5 mm (5.41” x 2.83” x 0.65”)

Weight: 196 g (0.43 lb.)

Packing

Dimensions (WxDxH): 173 x 100 x 47 mm (6.81” x 3.94” x 1.85”)

Weight: 330 g (0.73 Ib.)

Environmental specifications

Operating

Temperature: 0°C to 40°C (32°F to 104°F)

Humidity: 5% to 95% (Non-condensing)

Storage

Temperature: -20°C to 60°C (-4°F to 140°F)

Humidity: 5% to 95% (Non-condensing)

Certifications

CE/Safety

WEEE

2011/65/EC (RoHS) Restriction of Hazardous Substances Directive

HSF (Hazardous Substance Free)

European Parliament and Council Directive 94/62/EC of 20 December 1994 on packaging and packaging waste

Package contents

Type-A to Type-C USB cable

Quick Start Guide

Safety warning

Ovenstående informationer/specifikationer er vejledende og kan uden varsel være ændret af producenten.
Der tages forbehold for trykfejl og billederne er vejledende.
